BONOMI SERIES 710062 2-WAY ST. ST. BODY 3-PIECE BW ENDS BALL VALVE AND VALBIA PNEUMATIC ACTUATOR
BONOMI SERIES 710062 2-WAY ST. ST. BODY 3-PIECE BW ENDS BALL VALVE AND VALBIA PNEUMATIC ACTUATOR - 3/8" BW ENDS / DOUBLE ACTING
Shipping Weight:
Delivery and Shipping
Delivery and Shipping
Most valves and actuator have a shipping time of 1-7 days + transit time, subject to availability.
Small orders for valve assemblies placed with a UPS Next Day Air or 2nd Day Air shipping via, will ship the same or the following day.
We will notify you if lead time is extended.
Contact us if you have any questions.
BONOMI SERIES 710062 2-WAY ST. ST. BODY 3-PIECE BW ENDS BALL VALVE ...
The BONOMI SERIES 710062 2-WAY ST. ST. BODY 3-PIECE W/ BW ends BALL VALVE AND VALBIA PNEUMATIC ACTUATOR is a unique product that offers a variety of features. It is made of stainless steel w/ BW ends for steam and comes in full port sizes from 1/4” to 4”. It has a working pressure of 1000 psi (3/8” to 1/2”), 600 psi (3/4” to 1”), 350 psi (1-1/4” to 2”), and 230 psi (2-1/2” to 4”) - 250 steam. The temperature range is -4°F to 406°F.
The product also features a blow out proof stem, adjustable stem packing, 25% carbon filled P.T.F.E. ball seats, ISO 5211 mounting pad with double “D” stem, 100% electronically tested in the open and closed position at 80 psi, TUV T.A. Luft approved with Double acting or spring return actuator, Hard anodized extruded aluminum body, Concentric spring sets, Die cast aluminum end caps, Solid steel barstock pinion (not casting), 0°-90° rotation adjustment cam, 0°-90° rotation adjustment bolts, and POM piston guides.
-
Assembly Description
-
Data Sheet
-
Valve Type
-
Temperature Rating
-
Pressure Rating
-
Valve Body Type
-
Approvals
-
Valve Body Configuration
-
Valve Connection Type
-
Body Material
-
Actuator Housing Material
