BONOMI 8E866LF WITH SERIES RB 365NLF 3-WAY LEAD FREE BRASS NPT BALL VALVE AND PLASTIC VALBIA ELECTRIC ACTUATOR

Elevate your system with the extraordinary BONOMI 8E866LF, a Lead-Free Brass 3-way L-Port NPT ball valve matched with the high-performance Plastic Valbia electric actuator. Revolutionize your approach to drinking water applications. Crafted with a Lead-Free Brass L-Port design spanning from 1/4” to 3”, this valve ensures both compliance and excellence. Featuring an ISO 5211 pad and square stem, pressure rating up to 400 WOG, and a temperature range from -4°F to 366°F, its four-seat design, blow-out proof stem, and T.E.A. coated LF brass ball assure durability. With a low torque design, double o-ring stem seal, and 100% electronic testing at 80 Psi, its reliability knows no bounds. With 24V AC/DC & 100-240V AC models available, and cycle times that cater to your needs, the actuator combines high-strength, impact resistance, and an IP65 Technopolymer housing for optimal performance. Featuring an auxiliary SDPT contact on closed position, LED light in open position, and quiet operation, its 89 in. lbs. output torque is complemented by a 30" pigtail for easy installation. Absorbed current for both 120V AC and 24V AC/DC is thoughtfully engineered for efficient operation. Don't wait – get yours now and experience the pinnacle of innovation and resilience for industrial environments.
