BONOMI SERIES BFVSTCE 2-WAY ST. ST. BODY SANITARY TRI-CLAMP BUTTERFLY

"Explore BONOMI SERIES BFVSTCE 2-WAY ST. ST. BODY SANITARY TRI-CLAMP BUTTERFLY VALVE AND VALBIA PNEUMATIC ACTUATOR is our high-performance Direct Mount Stainless Steel Butterfly Valve with EPDM Seats and Pneumatic Actuator, featuring Sanitary Tri-Clamp Ends. Perfect for Water, Gas, Oil, and Chemical applications. Crafted from AISI 316L Stainless Steel, this valve offers a Full port design in sizes ranging from 1/2" to 12". Its precision meets the highest standards with Sanitary Tri-Clamp Ends, 3-A, FDA, and USDA approved surface finish. The valve boasts a 13-position spring-loaded lever lock handle (1/2" to 6"), ensuring optimal control. With a robust build, it handles up to 110 psi @ 200°F, supported by EPDM seats for reliability.

The included Pneumatic Actuator is equally impressive, featuring a hard anodized aluminum body, die-cast aluminum end caps, and a solid steel barstock pinion for unmatched durability. Its 0°-90° rotation adjustment cam and bolts offer precise control. With POM piston guides and a working temperature range of -4°F - 302°F, it's built to excel. Enjoy peace of mind with air pressure ratings of 80 psi (minimum) to 116 psi (maximum). Plus, its maintenance-free design ensures worry-free operation throughout its lifetime. Backed by rigorous factory testing, this assembly guarantees performance and reliability."

Assembly Description

BONOMI DABFVSTCE WITH SERIES BFVSTCE, 1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA52V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 3/4" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA52V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 1" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA52V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 1-1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA63V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA75V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 2-1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA75V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 3" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA75V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 4" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA75V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 6" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA100V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI DABFVSTCE WITH SERIES BFVSTCE, 8" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA DA100V DOUBLE ACTING PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SR63V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 3/4" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SR63V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 1" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SR75V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 1-1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SR75V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SR85V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 2-1/2" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SE85V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 3" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SE100V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 4" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SE115V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 6" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SE140V SPRING RETURN PNEUMATIC ACTUATOR
BONOMI SRBFVSTCE WITH SERIES BFVSTCE, 8" SANITARY TRI-CLAMP, BRACKET MOUNT, ST. ST. BODY, FULL PORT, 2-WAY BUTTERFLY VALVE AND VALBIA SE140V SPRING RETURN PNEUMATIC ACTUATOR
Data Sheet

Download
Valve Type

BUTTERFLY VALVE
Temperature Rating

0 °F to 300 °F
Pressure Rating

110 PSI
Valve Body Type

SANITARY
Valve Body Configuration

2-WAY
Valve Connection Type

Sanitary Tri-Clamp Ends
Body Material

STAINLESS STEEL
Actuator Housing Material

Hard Anodized Aluminum
